All reconcile circuits
These are all the circuits that exist in the reconcile tables related to the selected NMS
In NMS not in IMS
This means that the circuits have been found in the network but do not exist in IMS.
Possible causes
oOne of the related objects does not exist in IMS like Site, Domain, IP-address, Vendor etc. Check the error message column.
Solution
oCreate missing objects in IMS
The circuit already exists in IMS but has a different Network ID
Solution
oDelete the old Network ID (NMSID) and relate the new reconcile circuit to the IMS circuit
Status MI
This is a list of all the circuits in IMS related to the selected network platform that has the status MI. This means that those circuits will not be touched during the reconcile process because someone is still planning those circuits in IMS.
oCheck who is working on the circuit and ask them what the actual status is.
Port or carrier delta
This is a list of circuits that have one or more ports or carrier discrepancies. This means for example, a circuit in IMS is connected from:
Node A / Port 1 to Node B / Port 1
And in the network the circuit is connected from:
Node A / Port 1 to Node B / Port 2
In this case there is a delta on Node B Port 1 in IMS and Node B port 2 in the reconcile data. Then this circuit will appear in this list. This will also work in the same way for the Carrier delta.
All circuit ports
This lists all the circuits from the reconcile circuit table that has a relation to one or more ports in the reconcile table.
